FRONIUS RESERVA 3.15kWh
Solar Battery Module
AUS-NZ

High-voltage LFP battery module with 3.15kWh usable capacity, 102.4V nominal voltage, IP65 protection, and modular expansion for compatible Fronius Reserva systems.
Solar Battery

FRONIUS RESERVA 3.15kWh Solar Battery Module – AUS-NZ

The FRONIUS RESERVA 3.15kWh Battery Module is a high-voltage LFP battery module providing 3.15kWh of usable energy, 102.4V nominal voltage, and modular expansion capability for compatible Fronius Reserva systems.

$5,400.00
Inc. GST / Per Panel
In Stock
Brand FRONIUS
SKU / Model RESERVA BATTERY MODULE 3.15 kWh AUS-NZ
Warranty 10 Years – subject to manufacturer warranty terms
Compatible With
  • Fronius Reserva Battery System and compatible Fronius hybrid inverters
Add to Cart Download Datasheet
10 Years – subject to manufacturer warranty terms Performance Warranty
250 × 772 × 176mm (H × W × D) Dimensions
Approx. 26 kg Weight
IEC 62619:2022, CE, VDE 2510-50, IEC 62477-1, UN 38.3 Certificate
Product Description

FRONIUS 3.15kWh Battery Module

The FRONIUS RESERVA Battery Module is a high-voltage lithium iron phosphate (LFP / LiFePO₄) battery module designed for residential solar energy storage applications. With 3.15kWh of usable capacity and a modular design, it provides reliable energy storage with expansion capability for compatible Fronius Reserva systems.

Product Description

Battery Technical Specifications

Specification Value
Model Fronius Reserva Battery Module
Module Capacity 3.15 kWh
Battery Chemistry Lithium Iron Phosphate (LFP / LiFePO₄)
Nominal Voltage 102.4 V DC
Usable Energy 3.15 kWh
Maximum Charge Current 32 A
Maximum Discharge Current 32 A
Protection Rating IP65
System Type High-Voltage Energy Storage
Compatibility
Inverter
  • Compatible Fronius hybrid inverters; confirm supported models
Battery Systems
  • FRONIUS RESERVA
System Types
  • Hybrid Solar Systems
  • Battery Energy Storage Systems
  • Residential Energy Storage
  • High-Voltage Energy Storage
  • Backup Power Systems
Other
  • Solar PV Systems
  • Energy Management
  • Load Shifting
  • Self-Consumption
  • Backup Power
  • Energy Storage
